Python: Basic Image processing techniques using open-cv
What is opencv
What is opencv
OpenCV-Python is a library of Python bindings designed to solve computer vision problems, apart from computer vision can be also used for image processing.
How to install opencv
Using pip we can install opencvpip install opencv-python
How to import opencv to our python script
The import statement loads libraries, cv2 is the opencv library name of opencv in python.import cv2
How to read an image with opencv
Assuming we have an image file named cat.jpg, to read the image use the following.img = cv2.imread("cat.jpg")
How to get image properties
After reading the image we can extract its properties in a tuple structure. The first element is the width, second is the height and third the number of channels (Note that opencv does not use RGB, but instead uses BGR).>>> print(img.shape)
(534, 799, 3)
How to convert from BRG to RGB color format
If we want to display the image in other libraries like matplotlib which reads the images in RGB format we need to convert the image.
RGB_img =How to resize image by ratio
We need first to set the ratio, we want to resize it by 50% in this example>>> ratio_resize = 50
>>> width = int(img.shape[1] * ratio_resize / 100)
>>> height = int(img.shape[0] * ratio_resize / 100)
>>> new_size = (width,height)
>>> img_resized = cv2.resize(img,new_size)
>>> print(img_resized.shape)
(267, 399, 3)
How to resize image horizontally
In this case we will give to new_width the value we want, the interpolation property calculates pixel values for the new image from the original one.>>> new_width = 100
>>> new_size = (new_width,img.shape[0])
>>> img_resized = cv2.resize(img,new_size,interpolation=cv2.INTER_AREA)
>>> print(img_resized.shape)
(534, 100, 3)
How to resize image vertically
Using an almost similar technique we resize an image vertically.>>> new_height = 100
>>> new_size = (img.shape[1],new_height)
>>> img_resized = cv2.resize(img,new_size,interpolation=cv2.INTER_AREA)
>>> print(img_resized.shape)
(100, 799, 3)
How to rotate image 90 degrees clockwise
Rotating an image is super easy!>>> img = cv2.rotate(img, cv2.ROTATE_90_CLOCKWISE)
>>> print(img.shape)
(799, 534, 3)
How to rotate image 90 degrees counter-clockwise>>> img = cv2.rotate(img, cv2.ROTATE_90_COUNTERCLOCKWISE)
>>> print(img.shape)
(534, 799, 3)
How to rotate an image horizontally>>> img = cv2.flip(img, 1)
How to rotate an image vertically>>> img = cv2.flip(img, 0)
How to convert image to grayscale
gray_image =How to save image
Also saving images is very easy!
cv2.imwrite('filename.jpg',img)I hope you found this article easy to read and inspired you to use opencv in future projects!
